Fully Automatic Handheld/Portable Density Meter for The Lab/Laboratory or The Field (U-shaped Vibrating Tube)
Fully Automatic Handheld/Portable Density Meter for The Lab/Laboratory or The Field (U-shaped Vibrating Tube)
Fully Automatic Handheld/Portable Density Meter for The Lab/Laboratory or The Field (U-shaped Vibrating Tube)
Fully Automatic Handheld/Portable Density Meter for The Lab/Laboratory or The Field (U-shaped Vibrating Tube)
Fully Automatic Handheld/Portable Density Meter for The Lab/Laboratory or The Field (U-shaped Vibrating Tube)
Fully Automatic Handheld/Portable Density Meter for The Lab/Laboratory or The Field (U-shaped Vibrating Tube)
Price
US $3600-4300
Model
DSM-G
Min. Order
5 piece

Item specifics

Measuring range
0.65g/cm3〜1.0g/cm3
Accuracy
±0.0005g/cm3
Resolution
0.0001g/cm3
Density accuracy
±0.0005g/cm3
Power supply
Rechargeable lithium battery 3.8V
Sample volume
2 ml sample

Review

Description

1. Introduction

Fully Automatic Handheld/Portable Density Meter for The Lab/Laboratory or The Field (U-shaped Vibrating Tube)


It is a precision instrument for measuring liquid density, temperature, concentration and specific gravity. The density and temperature can be quickly measured in a few seconds with 2ml sample, and converted into standard density, concentration and specific gravity at the same time. It adopts the U-shaped vibrating tube measurement principle, and the density accuracy reaches ± 0.0005g/cm ³ and the temperature accuracy reaches ± 0.1 . It is suitable for liquid density measurement in petrochemical, pharmaceutical and food industries, and can completely replace the traditional manual density measurement.

With the ergonomic design, light, intuitive and durable, multiple effective measurements can be carried out at any position and by any person. It can be used for precision measurement in the laboratory as well as rapid detection outdoors. It is a revolutionary instrument that can completely replace manual density meters in the real sense.

The measurement data can be permanently saved, traced at any time, or uploaded for data analysis. It has been applied in many large petroleum and petrochemical enterprises such as PetroChina, China Aviation Oil, CNOOC, Sinopec and shell, and has successfully solved the current density measurement problem.

2. Advantages

1. The density and temperature can be quickly measured in a few seconds with 2ml sample, and converted into standard density, concentration and specific gravity at the same time.

2. RAM: 3000 Group  other brand:  1024 Group

3. Specifications



              Density
Measuring range
0.65g/cm31.0g/cm3
Accuracy
±0.0005g/cm3
Resolution
0.0001 g/cm3


           Temperature
Temperature
0 40
Accuracy
±0.1
Resolution
0.01


       Electrical parameters
Power supply
Rechargeable lithium battery 3.8V
Continuous working hours
10 Hours
Data storage
Group 3000

     Mechanical parameters
Weight
0.55 kg
Size
240mm×80mm×125mm
   Environmental parameters
Environmental temperature
-10—60
        Explosion proof
Explosion-proof grade
Ex ia IIC T4 Ga
               Viscosity
Measurement requirements
<23mPa·s
         Authentication
Explosion proof certification, calibration certificate, verification certificate
       Reference standard                         specification
JJG1058-201 Os JJG370-2007
4.  Features & Benefits

       1.Improve work efficiency and greatly reduce the measurement time

Simple operation. After inhaling the liquid, the measurement results can be given in a few seconds, which greatly improves the work efficiency

       2.Reduce sample waste
Only 2ml sample is needed to complete the measurement, which can not only ensure that the oil sample by analytical method is not polluted, but also ensure less sampling volume and avoid the pollution caused by oil backflow.

       3.The measurement data is traceable, accountable and permanently stored
The instrument can store 5000 groups of data, which can not be modified or deleted, and can be uploaded to the computer or printed directly for data tracing and query.

       4.Multi-purpose and multi occasion
The instrument has explosion-proof qualification and can be used in any environment. The display can be rotated and used as a desktop device.
5. Package
6. Company Information
